Importing and Manipulating Data Frames

Learning Objectives

• Load external tabular data from a .csv file into R.
• Describe what an R data frame is.
• Summarize the contents of a data frame in R.

Loading and examining an example data set

We are studying a population of Escherichia coli (designated Ara-3), which were propagated for more than 40,000 generations in a glucose-limited minimal medium. This medium was supplemented with citrate which E. coli cannot metabolize in the aerobic conditions of the experiment. Sequencing of the populations at regular time points reveals that spontaneous citrate-using mutants (Cit+) appeared at around 31,000 generations. This metadata describes information on the Ara-3 clones. Read more about the Long Term Evolution Experiment here from Lenski.

The metadata file required for this lesson can be downloaded directly here. This data was taken from the Blount et al. paper in Nature.

The columns stand for:

Workspace set up

There are some functions within R that let you create folders and see what is in them. This can be useful for confirming for making output folders from your scripts and checking if files are present (the alternative is using the clickable options within RStudio). We will create the folder using the dir.create() function and confirm that the folder is empty using the list.files() function. You can also download files directly from within R using the download.file function

## dir.create is the function for making a new folder (directory)
dir.create('data')

## you can use the list.files() function to see what files are present in a folder
list.files("data")

## Now you can put the metadata file from the course materials into the data folder

Downloading the data

We have put the data file within a shared folder on Google Drive so it is simpler to download the file manually and then add it (there is a googledrive R package but we are not using it here)

A demonstration of downloading the file directly from Google Drive using download.file() is shown below;

## DO NOT RUN - This is the link to the file on Google Drive but it may require authentication
#download.file(url="https://drive.google.com/uc?export=download&id=1yg29Yol0FlkUnjS78qkoWxHdA3bvijZu" ,destfile="data/Ecoli_metadata.csv")

Checking that the file is in the data folder

You can check that the file is in the data folder using the files panel in RStudio or you can use R functions such as list.files or file.exists as shown below

list.files("data")
# should show "Ecoli_metadata.csv" in the console
file.exists("data/Ecoli_metadata.csv")
# returns TRUE if the file is present or FALSE if the file is not present

Loading the data into R

You are now ready to load the data. As the data is in the csv (comma-separated values) format, we are going to use the R function read.csv() to load the data file into memory (as a data.frame):

metadata <- read.csv('data/Ecoli_metadata.csv')

This statement doesn’t produce any output because the assignment doesn’t display anything. If we want to check that our data has been loaded, we can run some checks on our new object: metadata

Let’s check the top (the first 6 lines) of this data.frame using the function head():

head(metadata)

##     sample generation   clade strain     cit       run genome_size
## 1   REL606          0    <NA> REL606 unknown                  4.62
## 2 REL1166A       2000 unknown REL606 unknown SRR098028        4.63
## 3   ZDB409       5000 unknown REL606 unknown SRR098281        4.60
## 4   ZDB429      10000      UC REL606 unknown SRR098282        4.59
## 5   ZDB446      15000      UC REL606 unknown SRR098283        4.66
## 6   ZDB458      20000 (C1,C2) REL606 unknown SRR098284        4.63

We’ve just done two very useful things.

1. We’ve read our data in to R, so now we can work with it in R

2. We’ve created a data frame using the read.csv() function. We didn’t have to specify a dataframe when using read.csv() as it is the default format that the function will return to you

Some more about read.csv and loading data

read.csv() is an example of a “wrapper” function as it uses read.table() inside of it but with the default arguments changed to what is required for a loading a .csv file. Running read.table("data/Ecoli_metadata.csv", sep = ",", header = TRUE) is the same as running read.csv("data/Ecoli_metadata.csv")

If the data was in .tsv format then you could use read.table("data/Ecoli_metadata.csv", sep = "\t", header = TRUE) instead.

There are functions for loading all sorts of data types into R but you will typically need to install other R packages (eg read.xslx() from the openxlsx package for excel files and Read10X()/ReadXenium()/Load10X_Spatial() from the Seurat package for single cell and spatial data)

Debugging errors

Let’s create a very common error that you will encounter.

(metadata <- read.csv('dataa/Ecoli_metadata.csv'))

Error in file(file, "rt") : cannot open the connection
In addition: Warning message:
In file(file, "rt") :
    cannot open file 'dataa/Ecoli_metadata.csv': No such file or directory

What to do when you get an error

1. Don’t panic - you are not special

2. First read the error message - what does it say? > Often you end up with general error messages that might not be very helpful for diagnosing the problem (e.g. “subscript out of bounds”).

3. Next, check your code for common errors (a) matched brackets (b) matched quotation marks (c) correct names/typos. Is the text in your text editor the correct colour?

4. Then, google the error message or paste it into your LLM of choice along with the code used to generate the error. Pasting code into an LLM is generally safe (as most often you will be using publicly available code) but it is better to use LLMs that Garvan has an enterprise agreement with. Avoid pasting in any sensitive information (eg patient IDs) and direct file paths to where your data is kept

5. You can also check support sites such as github or stackoverflow.com. For stackoverflow, search using the [r] tag. Most questions have already been answered, but the challenge is to use the right words in the search to find the answers: http://stackoverflow.com/questions/tagged/r. If your issue is specific to a particular R package then you can also go to the issues section of the github page and look to see if anyone else has had the same problem (eg. https://github.com/satijalab/seurat/issues)

Exercise

On your table can you please try to create a unique error message?

What are data frames?

A data.frame is a collection of vectors of identical lengths. Each vector represents a column, and each vector can be of a different data type (e.g., characters, integers, factors). The str() function is useful for inspecting the data types of the columns.

By default, data.frame coerces columns that contain characters (i.e., text) into the factor data type. Depending on what you want to do with the data, you may want to keep these columns as character. To do so, read.csv() and read.table() have an argument called stringsAsFactors which can be set to FALSE:

Let’s now check the structure of this data.frame in more details with the function str():

str(metadata)

Inspecting data.frame objects

We already saw how the functions head() and str() can be useful to check the content and the structure of a data.frame. Here is a non-exhaustive list of functions to get a sense of the content/structure of the data.

• Size:
  • dim() - returns a vector with the number of rows in the first element, and the number of columns as the second element (the dimensions of the object)
  • nrow() - returns the number of rows
  • ncol() - returns the number of columns
• Content:
  • head() - shows the first 6 rows
  • tail() - shows the last 6 rows
• Names:
  • names() - returns the column names (synonym of colnames() for data.frame objects)
  • rownames() - returns the row names
• Summary:
  • str() - structure of the object and information about the class, length and content of each column
  • summary() - summary statistics for each column

Note: most of these functions are “generic”, they can be used on other types of objects besides data.frame.

Challenge

Based on the given table of functions to assess data structure, can you answer the following questions?

1) What is the class of the object metadata?

2) How many rows and how many columns are in this object?

3) What are the column names for this data frame?

Subsetting Data frames

The metadata data frame has rows and columns (it has 2 dimensions), if we want to extract some specific data from it, we need to specify the “coordinates” we want from it. Row numbers come first, followed by column numbers (i.e. \(row, column\)).

metadata[1, 2]   # 1st element in the 2nd column
metadata[1, 6]   # 1st element in the 6th column
metadata[1:3, 7] # First three elements in the 7th column
metadata[3, ]    # 3rd element for all columns
metadata[, 7]    # Entire 7th column

Using column names to subset data frames

For larger datasets, it can be tricky to remember the column number that corresponds to a particular variable. Sometimes the column number for a particular variable can change if your analysis adds or removes columns. The best practice when working with columns in a data frame is to refer to them by name. This also makes your code easier to read and your intentions clearer.

There are two ways to select a column by name from a data frame:

• Using dataframe[ , "column_name"]
• Using dataframe$column_name

You can do operations on a particular column, by selecting it using the $ sign.

In this case, the entire column is a vector. To see the possible columns names run

names(metadata)
colnames(metadata)

To subset just the strain column from the metadata or

metadata[ , "strain"]

metadata$strain

The first method allows you to select multiple columns at once. Suppose we wanted strain and clade information:

metadata[, c("strain", "clade")]

You can even access columns by column name and select specific rows of interest. For example, if we wanted the strain and clade of just rows 4 through 7, we could do:

metadata[4:7, c("strain", "clade")]

Exercise

Create a new variable of a dataframe that contains just the sample and genome size.

Why would you create a subset of the original dataframe?

Factors

In the data frame we just imported, let’s do:

str(metadata)

As you can see, many of the columns in our data frame are character datatypes. However, there is also a special class called factor.

They are very useful but not necessarily intuitive and therefore require some attention.

Factors are used to represent categorical data. Factors can be ordered or unordered. They are an important class for statistical analysis and for plotting.

Factors are:

• stored as integers
• have labels associated with these unique integers.
• While factors look (and often behave) like character vectors, they are actually integers under the hood, and you need to be careful when treating them like strings.

Let us convert the clade columns from a character to a factor column using the factor command.

factor(metadata[,3])

The levels associated with this factor are Levels: (C1,C2) C1 C2 C3 Cit+ UC unknown.

Exercise

Let’s reread our metadata data frame, but set every character column to be a factor.

By looking at the help page, can you edit the command below with a new argument that would read all strings as factors?

metadata <- read.csv('data/Ecoli_metadata.csv')

## Note that this is not the default option for read.csv and it is better
## to set the columns that you want to be factors as factors rather than
## making every character column a factor

Factors are character vectors that can only contain a pre-defined set of values known as levels. By default, R always sorts levels in alphabetical order.

For instance, we see that cit is a Factor w/ 3 levels, minus, plus and unknown. We can check and change the order of the levels using the levels() function. To demonstrate changing the order, we will add a new column with a different ordering to our dataframe. Reordering levels of a factor is a common process that you will need to do

levels(metadata$cit)

## make a new variable by using the <- symbol

metadata$cit_unknown_first <- factor(metadata$cit,levels=c("unknown","minus","plus"))

## Check the output


Exercise

Let’s test what happens if we capitalise the levels. How would you check the output column?

metadata$cit_capitalised <- factor(metadata$cit,levels=c("Unknown","Minus","Plus"))

This demonstrates how the levels of a factor must match what is actually present in the column. Note that it does not return an error so it is important to check your output!

Appendix - Additional tips for loading data

Another useful argument to read.csv is na.strings. This argument tells read.csv if you want to convert anything from your raw data into NA. Converting missing data to NA means that you can use R functions like is.na() to deal with them later

## Anything matching `NA,""," ", or "Not Detected" will be converted to NA.
## This is useful if you have been given data where someone has used a different
## term for missing data (e.g "Not Detected")
metadata <- read.csv('data/Ecoli_metadata.csv',na.strings = c(NA,""," ","Not Detected"))

Larger data sets

read.csv() can fail or be very slow at reading files more than a few hundred MB in size. In this case, you can look into the data.table package. It has functions for loading and running analyses on larger datasets

Material adapted from (https://datacarpentry.org/R-genomics/01-intro-to-R.html) and (https://datacarpentry.org/semester-biology/materials/r-intro/) by Helen King. Further revisions by the Data Science Platform.
